Model | ZL50-29 | ||||||||
Working Voltage Range | DC: 6V-24V | ||||||||
Rating Power | 6V: 0-11.5W/12V: 0-11.5W/24V: 0-15W | ||||||||
Static Water Head | 0-5 M | ||||||||
Static Flow Rate | 0-12 L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000hrs | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non Submergible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <30dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature ≤70℃ | ||||||||
Application | Warm water mat, warm water mat, warm water cushion, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remarks | |||||
Length (mm） | Width（mm） | Height（mm） | OD （mm） | ID （mm） | OD （mm） | ID （mm） | Inlet and outlet with footgrip | ||
60 | 50 | 72 | IP68 | φ16 | φ12 | φ10 | φ6.5 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
