| Model | ZL38-42 | |||||||
| Working Voltage Range | DC：6-24V | |||||||
| Rating Power | 6V：2-12W / 12V：3-18W / 24V：5-20W | |||||||
| Static Water Head | 1-6M | |||||||
| Static flow rate | 4-10Litre / minute | |||||||
| Lifespan | Continuous operation under normal working condition ≤ 24 hours, service life＞20000hour | |||||||
| Working Environment | PH value：PH5-10（Weak acid and weak base）、non-Submersible pump | |||||||
| Max Noise | Continuous operation under normal working condition (water pump is 1m away from the tester)＜35dB | |||||||
| Max Working Temperature | At room temperature, the temperature of the aqueous medium≤70℃ | |||||||
| Application | Agricultural and forestry drip irrigation, pipeline hot water circulation, solar water heater, small fountain, aquarium, etc | |||||||
| Size | IP Grade | Inlet | Outlet | Remarks | ||||
| Length (mm) | Width (mm) | Height (mm) | OD (mm) | ID (mm) | OD (mm) | ID (mm) | In and out with filter cover | |
| 151 | 50 | 80 | IP68 | Φ12 | φ9 | φ12 | Φ9 | |
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
